Folding Machine

sheet width 1020 mm︱plate thickness 2 mm︱upper clamping bar swivable ja ︱weight of the machine ca. 500 kg︱dimensions of the machine ca. 1500 x 600 x 1450 mm︱

---

manual folding machine Type ASK 205-1 2 identical machines in stock

sheet width 3100 mm︱plate thickness 6 mm︱thickness at "Niro-steel" 4,5 mm︱daylight upper clamping 100 mm︱Bending angle 0 - 135 °︱total power requirement 7,4 kW︱weight of the machine ca. 7,6 t︱dimensions of the machine ca. 4,5 x 1,72 x 2 m︱Electric 380 Volt ︱manuel back gauge adjustable from the front 70 - 600 mm︱Foot switch with emergency stop ︱Segmented upper tool ︱Oil filling exklusive ︱Video available on our website. ︱

---

Machine dealer with own stock of 2500 m².

sheet width 1020 mm︱plate thickness 2,5 mm︱bending angle max. 135 °︱stroke of upper beam 25 mm︱weight of the machine ca. 285 kg︱dimensions of the machine ca. 1,35 x 0,85 x 1,20 m︱

---

*** PRICE: 1.899,-- EUR *** - with an oblique segmented upper cheek - distribution segment: 25-30-35-40-45-50-75-100-150-200-270 - done with the foot brake application

sheet width 1050 mm︱plate thickness 1,5 mm︱distance between columns mm︱daylight opening 100 mm︱weight of the machine ca. 330 kg︱dimensions of the machine ca. 1,6 x 0,9 x 1,45 m︱

---

- Split upper, lower and rear tool - Upper tool with quick change system - Quick foot clamp - Angle stop - lockable - manual backgauge 500 mm - mobile

sheet width 1250 mm︱plate thickness 1,25 mm︱distance between columns mm︱daylight opening 100 mm︱bending angle max. 135 °︱plate width at 30 kg/mm 2,0 ALU ︱thickness at "Niro-steel" 0,8 VA mm︱weight of the machine ca. 350 kg︱dimensions of the machine ca. 1,715 x 0,75 x 1,4 m︱

---

- Divided upper, lower and rear tool - Upper tool with quick change system - Foot quick clamp - Angle stop - lockable - manual back gauge 500 mm - mobile

sheet width 3200 mm︱Sheet thickness aluminum 2,0 mm︱ 1,5 mm︱sheet thickness for stainless steel 1,0 mm︱daylight opening 120 mm︱Control NC TouchScreen ︱back stop - adjustable 10 - 750 mm︱bending angle max. +/- 150 °︱total power requirement 3 kW︱machine weight ab. 2250 kg︱dimensions of the machine ca. 4200 x 1700 x 1350 mm︱

---

Biegewinkel 150° ︱sheet width 1020 mm︱plate thickness 2,0 mm︱distance between columns -- mm︱weight of the machine ca. 0,36 t︱dimensions of the machine ca. 1,28 x 0,62 x 1,2 m︱

---

Manual folding machine FSBM 1020-20 HSG / 3770103 - The workpiece is clamped using a foot pedal, so both hands remain free for material feed - Different tool variants available E, S2, HS2 and HSG - The strong auxiliary cylinder makes bending easier - Wide clearance between the upper and lower beam of up to 25 mm - Self-lubricating slide bearings - Clamping pressure of the upper beam can be easily adjusted using handy knurled screws - Adjustment of the material thickness by means of a knurled screw - Adjustable stop for bending angle Equipment details: FSBM 1020-20 HSG - With segmented goat foot tools, segmented bending bar and segmented bed pad - Segments have a hardness of HRC24-26 VA steel 1.2 mm Aluminum 2.4 mm

sheet width 2020 mm︱plate thickness 1,5 mm︱distance between columns -- mm︱bending angle max. +/- 135 °︱hollow max. 100 mm︱total power requirement 0,55 / 1,0 kW︱weight of the machine ca. 1,0 t︱dimensions of the machine ca. 2,68 x 0,64 x 1,1 m︱

---

Heavy version with motorized drive for the upper and bending beam and segmented upper beam / 3772940 - Foot control enables the sheet metal to be positioned with both hands - The workpiece is clamped and bent using a motorized chain drive - Setting the bending angle manually, reading the angle on a scale ring - Many bending options with segmented upper beam - Exact movement of the bending beam via large flat guides - Heavy, robust welded construction Segment division: 25-30-35-40-45-50-75-100-150-200-200-270-400-400 mm VA steel: 0.8 mm Aluminum: 2.0 mm

sheet width 1020 mm︱plate thickness 2,0 mm︱daylight opening ~ 54,0 mm︱bending angle max. 0 - 135 °︱total power requirement manuell ︱weight of the machine ca. 310 kg.︱dimensions of the machine ca. 1350 x 950 x 1170 mm︱

---

- Segmented upper and bending beam for a wide variety of bending options - Clamping by means of a foot pedal - Universally applicable bending machine for plumbing and repair shops - Robust construction in a modern design - Manual bending machine for standard bending tasks - Quick and easy bending process using a bow handle - Easy adjustment of the lower beam to the respective sheet thickness - High upper beam for producing high-edged profiles Furnishing : - Segmented upper cheek - Segmented lower cheek - Foot clamp - Fixed stop angle adjustment

sheet width 1020 mm︱plate thickness 2,5 mm︱distance between columns 1045 mm︱daylight opening max. 47 mm︱bending angle max. 135 °︱weight of the machine ca. 290 kg︱dimensions of the machine ca. 1,35 x 0,86 x 1,17 m︱

---

Sengmentable upper rail, upper clamping foot-operated, manual bending clamping operate. Machine dealer with own stock of 2500 m².

sheet width 2020 mm︱plate thickness 2,5 mm︱control Beijer ︱daylight upper clamping 100 mm︱Bending angle 0 - 135 °︱upper clamping drive 0,375 kW︱bend clamping drive 1,125 kW︱weight of the machine ca. 2,6 t︱dimensions of the machine ca. 3 x 1,1 x 1,75 m︱Foot switch with emergency stop ︱Segmented upper tool ︱Oil filling exklusive ︱Light barrier control ︱

---

Machine dealer with own stock of 2500 m².

sheet width 8020 mm︱plate thickness 1,50 mm︱distance between columns mm︱bending angle 142 °︱depth 1000 mm︱number of stands 7 Stück︱throat 1000 mm︱upper beam stroke 200 mm︱total power requirement kW︱weight of the machine ca. 4,50 t︱dimensions of the machine ca. 1800 x 9500 m︱

---

with electric roller shears, with running cable box, bending angle for Setting, sheet thickness adjustment manually Machine has been checked by a specialist and is functional.

sheet width 2540 mm︱plate thickness 2,00 mm︱distance between columns mm︱bending angle 160 °︱daylight opening 300 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. 3,65 x 1,20 x 1,60 m︱

---

motorized Fasti swivel bending machine, well preserved, bending beam 14 mm, Attachment rail 30 mm, folding beam that can be lowered manually, emergency/off switch,foot pedal Machine is repaired by a specialist, checked, cleaned and is then full Functional. Test run is carried out.

sheet width 2020 mm︱plate thickness 1,5 mm︱distance between columns 2050 mm︱Daylight opening 100 mm︱total power requirement 0,75 kW︱weight of the machine ca. 1 t︱dimensions of the machine ca. 2,7 x 1 x 1,5 m︱

---

sheet width 1050 mm︱plate thickness 1,25 mm︱bending angle max. 135 °︱ 35 ︱weight of the machine ca. 80 kg︱dimensions of the machine ca. 1260 x 500 x 940 mm︱

---

sheet width 1270 mm︱plate thickness 1,5 mm︱bending angle max. 135 °︱ 50 mm︱weight of the machine ca. 477 kg︱dimensions of the machine ca. 1700 x 730 x 1335 mm︱

---

sheet width 1050 mm︱plate thickness 1,25 mm︱bending angle max. 135 °︱ 40 mm︱weight of the machine ca. 74 kg︱dimensions of the machine ca. 1260 x 500 x 940 mm︱

---

chamfer lenght 1050 mm︱plate thickness 1,2 mm︱distance between columns 1060 mm︱bending angle max. 135 °︱weight of the machine ca. 190 kg︱dimensions of the machine ca. 1,22 x 0,8 x 1,02 m︱

---

Light weight angle bending machine, for simple but effective bending work. Especially suited for making boxes. Due to its price this has proved a popular machine for workshops and DIY. Upper and lower blade are segmented. With metal box for the fingers. upper and lower blade segmented 1 hand operation

chamfer lenght 1050 mm︱plate thickness 1,2 mm︱distance between columns 1060 mm︱bending angle max. 135 °︱weight of the machine ca. 133 kg︱dimensions of the machine ca. 1,2 x 0,80 x 1,0 m︱

---

Light weight angle bending machine, for simple but effective bending work. Due to its price this has proved a popular machine for workshops and DIY. operation with 1 hand adjustable to material thickness adjustable lower blade

sheet width 3140 mm︱plate thickness 0,8 mm︱distance between columns -- mm︱ 145 °︱hollow 80 mm︱weight of the machine ca. 420 kg︱dimensions of the machine ca. 3200 x 950 x 1100 mm︱

---

chamfer lenght 2520 mm︱plate thickness 1 mm︱stroke of milling spindle 100 mm︱bending angle max. 0 - 135 °︱weight of the machine ca. 1310 kg︱dimensions of the machine ca. 3200 x 900 x 1370 mm︱

---

Heavy duty angle bending machine. The upper blade is segmented and the segments can be taken out. The work piece is clamped through foot control, which leaves both hands free. The machine is equipped with a cylinder and adjustable lower blade, which makes bending sheet metal very easy. European design. upper blade segmented cylinders on both sides foot pedal height can be set very accurately lower blade adjustable

chamfer lenght 1020 mm︱plate thickness 2 mm︱distance between columns 1350 mm︱bending angle max. 135 °︱stroke of upper beam 46 mm︱weight of the machine ca. 300 kg︱dimensions of the machine ca. 1,3 x 0,85 x 1,17 m︱

---

Heavy duty angle bending machine. The upper blade is segmented and the segments can be taken out. The work piece is clamp through foot control, which leaves both hands free. The machine is equipped with a cylinder and adjustable lower blade, which makes bending sheet metal very easy. European design. upper and lower blade segmented cylinders on both sides foot pedal height can be set very accurately lower blade adjustable

chamfer lenght 2020 mm︱plate thickness 1,5 mm︱stroke of milling spindle 100 mm︱bending angle max. 0 - 135 °︱weight of the machine ca. 1050 kg︱dimensions of the machine ca. 2700 x 900 x 1370 mm︱

---

Heavy duty angle bending machine. The upper blade is segmented and the segments can be taken out. The work piece is clamped through foot control, which leaves both hands free. The machine is equipped with a cylinder and adjustable lower blade, which makes bending sheet metal very easy. European design. upper blade segmented cylinders on both sides foot pedal height can be set very accurately lower blade adjustable

sheet width 1020 mm︱plate thickness 2,5 mm︱bending angle max. 135 °︱ 52 mm︱weight of the machine ca. 310 kg︱dimensions of the machine ca. 1360 x 800 x 1140 mm︱

---

The SCANTOOL SCAN 10S & 13S are manufactured with foot operated upper beam to allow for a simple and fast hands-free operation. The upper beam is fitted with a shapr nose segments for box and pan work. The segments can accommodate box profiles with a maximum edge height of 22 mm. The individual segments are mounted on a slide bar making it very easy to switch between standard straight folding and box and pan profiles. Both models can convert from segments to low sharp nose blade or radius blade. Accessories: Back gauge, radius blade R = 1,5 mm and R = 2,5 mm and ERGO uni
