desba TRADING Inhaber Batuhan Yilmaz - Stockist for used machines

turning diameter over bed 500 mm︱turning diameter over slide rest 300 mm︱turning length 1000 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

turning diameter 450 mm︱turning length 380 mm︱control Seicos ︱total power requirement 11 kW︱weight of the machine ca. 4,6 t︱dimensions of the machine ca. m︱

---

CNC lathe Hitachi Seiki HT 20 Year of construction 2000 Control Seicos Turning diameter 450 mm Turning length 380 mm travel range X 215mm Z 400 mm

turning diameter 165 mm︱turning length 300 mm︱control Seicos/Fanuc ︱total power requirement kW︱weight of the machine ca. 3,6 t︱dimensions of the machine ca. m︱

---

turning diameter 320 mm︱turning length 1100 mm︱control Fanuc ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

turning diameter 180 mm︱turning length 270 mm︱control Fanuc ︱total power requirement kW︱weight of the machine ca. 3,5 t︱dimensions of the machine ca. m︱

---

CNC lathe Mori Seiki cl 15 Year of construction 1995 Control Fanuc Turning diameter 180 mm Turning length 270 mm Spindle passage 33 mm without tailstock Weight approx. 3500 kg

turning diameter 340 mm︱turning length 850 mm︱control Philips ︱total power requirement kW︱weight of the machine ca. 6,4 t︱dimensions of the machine ca. m︱

---

turning diameter 520 mm︱swing diameter 420 mm︱turning height 200 mm︱Control Siemens ︱total power requirement kW︱weight of the machine ca. 3,8 t︱dimensions of the machine ca. m︱

---

x-travel 2500 mm︱y-travel 2400 mm︱z-travel 2000 mm︱bore diameter 130 mm︱total power requirement kW︱weight of the machine ca. 34 t︱dimensions of the machine ca. m︱

---

boring mill Collet & Engelhard TYPE BFf 130 Control Heidenhain Positip 855 Year of construction 1962 (Refurbished in 2016) turntable With many accessories/tools The traverse paths of the axes are as follows: X axis: 2500 mm Y axis: 2400 mm Z axis: 2000 mm B axis: 360° Table dimensions: 2000mm x 1780mm

x-travel 870 mm︱y-travel 280 mm︱z-travel 380 mm︱Control NC Digital ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 8000 mm︱y-travel 920 mm︱z-travel 1000 mm︱Control ︱total power requirement kW︱weight of the machine ca. 30 t︱dimensions of the machine ca. m︱

---

Year of construction approx. 1970 X 8000mm Y 920mm Z 1000 mm Head rotates 180° Table Length 3600mm Width 920mm

x-travel 400 mm︱y-travel 315 mm︱z-travel 400 mm︱Control Dialog 4 ︱total power requirement kW︱weight of the machine ca. 1,8 t︱dimensions of the machine ca. m︱

---

x-travel 600 mm︱y-travel 560 mm︱z-travel 560 mm︱Control Siemens Sinumerik 840 D ︱total power requirement 42 kW︱weight of the machine ca. 10 t︱dimensions of the machine ca. m︱

---

Horizontal machining center DMG DMC 60 H Year of construction: 2000 Control: Siemens Sinumerik 840D Travel paths: X 600mm Y 560mm Z 560 mm NC rotary table: 360x0.001° Distance measuring system: glass scales Tool holder: HSK-A 63 Number of pallets: 2 Pallet clamping area: 400x500 Internal coolant supply: 40 bar at 23 l/min Spray gun: on the pallet changer Viewing window: “Rotorclear” on the control door Cooling lubricant system: Vacuum rotation filter FRF 250/1250

x-travel 635 mm︱y-travel 510 mm︱z-travel 460 mm︱Control Siemens ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 500 mm︱y-travel 300 mm︱z-travel 350 mm︱Control FANUC 18i-M ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 580 mm︱y-travel 420 mm︱z-travel 420 mm︱Control Heidenhain ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 1020 mm︱y-travel 510 mm︱z-travel 500 mm︱Control Heidenhain ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 4200 mm︱y-travel 2750 mm︱z-travel 1650 mm︱control Fidia C20 ︱total power requirement kW︱weight of the machine ca. 40 t︱dimensions of the machine ca. 9500 x 5900 x 6400 m︱

---

• Traverse paths: X axis approx. 4,200mm, Y axis approx. 2,750mm, Z axis approx 1,650mm, °C axis approx. +/-275° and A axis +95° / -120° • Fixture space: approx. 3,000mm x approx. 2,200mm x approx. 980mm • Table size: 3,000mm x 2,200mm with T-slots in a 150mm grid • Table load: 1,000kg / m² table surface • Working and rapid traverse speed: max. 20m/min • Machine dimensions: length approx. 9,500mm (without housing), width approx. 5,900mm, height approx. 6,400mm (Z axis extended) • Weight: approx. 40,000kg • Controller: Fidia C20 • Spindle: HSK 63 from Fischer (Switzerland), 24,000 rpm (grease lubricated) • Spindle hours: 6,939 hours (as of 05/16/22) • Total hours: 76,793 hours (as of 05/16/22) • Tool changer: 2 tool magazines with 30 tool places each, max. Tool weight 4kg, max. tool diameter 80mm or Ø125mm if no two sister tool places, max. tool length 280mm cover plate pneumatic • Cooling: tool spray device with a container of 19.5 l, spray head with adjustable output 0.04 - max. 2.3l/h • Tool control: Blum Laser • Wireless probe: Manufacturer M&H, type 25.10, year of manufacture 2021 • Exchange ball screw X - axis 10.07.2018. • Telescope cover replaced on February 26, 2019 on one side.

x-travel 4000 mm︱y-travel 3500 mm︱z-travel 1500 mm︱Control Siemens Sinumerik 840 D ︱total power requirement 45 kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

Universal portal milling machine Pallet system: 2-fold traverse paths Pallet carrier longitudinal (X-axis): 4000mm Milling and drilling unit horizontal (Y-axis): 3500mm Spindle slide vertical (Z-axis): 1500mm Transom vertical (W axis): 1500mm Passage width between stands: 3000mm Headroom between pallet and spindle nose: 2500mm adjustment speeds X,Y,Z axis: 0 - 60000 mm/min W axis: 0 - 6000 mm/min Milling and drilling unit: M4 Drive power: 45kW Speed ??range of the milling and drilling spindle 1st stage: 5-1300 rpm 2nd stage: 23-6000 rpm Rated speed: 330 min-1 Max.torque: 1250Nm Cross section of the spindle slide: 400 x 400mm pallet system Number of pallets: 2 Clamping dimensions of the pallets: 2000 x 3000mm T-slots longitudinal: 28mm H8 Maximum workpiece weight: 10000kg Pallets are changed: manually using an indoor crane Number of setup stations: 2 main dimension Passage width b between the uprights: 3000mm Passage height h between pallet and spindle nose: 2500mm Total length L of the machine (without pallet system): approx. 10000mm Total width B of the machine (without pallet system): approx. 9770mm Total height H of the machine above ground: approx. 6650mm Accessories and Options - Renishaw probe - Automatic changing system for tools and processing units manipulator - Double gripper for changing tools in the machining units - Double gripper for changing processing units in de milling and drilling unit - Tool weight max. 50kg - Tool collar diameter 97.5 - 125mm - Max. weight for processing units 750kg shelf magazine - 4 shelves - 192 stations for tools - 4 stations for machining units - Tool holder ISO 50A according to DIN 69871 - Distance from station to station 140mm - Max. tool diameter when each station is occupied 135mm - Max. standard tool diameter 250mm / with direct feed via shuttle 315mm / max. tool length standard: 400mm / when stored in the top row of shelves (16 stations per shelf): 600mm - Subsequent supply - Main time parallel storage and retrieval or inspection of tools and processing units - Loading station with PC for entering, editing and managing tool data - Electrical equipment including motors and connection cables - Protective grille with automatic door to the working area - Operating instructions / documentation - Machine parameters on storage medium

grinding diameter 150 mm︱grinding length 500 mm︱centre height mm︱total power requirement kW︱weight of the machine ca. 0,9 t︱dimensions of the machine ca. m︱

---

grinding length 600 mm︱grinding width 300 mm︱workpiece height 300 mm︱total power requirement 5 kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

work piece width 250 mm︱workpiece height 35 mm︱bore diameter 2 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

table length 3235 mm︱table width 1545 mm︱burner heads ︱Control Mazatrol ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

x-travel 3000 mm︱y-travel 2000 mm︱z-travel 1000 mm︱Control ︱total power requirement 3 kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---

measuring machine Leitz 30 20 10 Year of construction 1990 Traverse paths / measuring range X 3000mm Y 2000mm Z 1000 mm Length 4915mm Width 3760mm Height 4062mm portal passage 2380x1915mm measurement accuracy ±0.003mm Maximum workpiece weight: 24,000kg

plate width 500 mm︱plate depth 630 mm︱plate height 10 mm︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱

---
